MIC-SCF-D

MIC-SCF-D

Delegate microphone for conference system mod. SCF-250

  • Crystal clear voice pick-up
  • Metal microphone base
In voorraad
Log in om je prijs te zien

Dit product kan niet worden toegevoegd omdat je niet bent ingelogd.

Toevoegen aan verlanglijst Vergelijk

Delegate microphone for conference system mod. SCF-250: Precision and clarity in every intervention

The MIC-SCF-D is a delegate microphone specifically designed to integrate with the SCF-250 conference system, allowing the connection of up to 64 microphones to cover large events with multiple participants. This microphone delivers high-quality performance in professional environments thanks to its unidirectional electret condenser capsule, which captures speech accurately while maintaining clarity and reducing unwanted ambient noise. With a frequency response ranging from 50 Hz to 20,000 Hz, it guarantees faithful sound reproduction in every intervention.

Highest audio quality and durability in professional use

  • High sensitivity: With a sensitivity of -42 dB and an impedance of 600 Ω, the MIC-SCF-D ensures excellent speech pick-up, even in environments with background noise.
  • Robust design: Capable of withstanding a maximum SPL of 128 dB, this microphone is ideal for picking up loud sounds without distortion, while maintaining a distortion (THD) of less than 1 % and a dynamic range of 95 dB.
  • Resistance in extreme conditions: Designed to operate in demanding conditions, the MIC-SCF-D operates correctly between -20 °C and 50 °C and can be stored in temperatures as low as -25 °C.

Why choose the MIC-SCF-D for your projects?

This microphone not only stands out for its sound quality, but also for its easy integration with the SCF-250 system, allowing the connection of up to 64 microphones, ideal for covering large conferences and meetings. It also features a 3-pin XLR connector, an LED indicator for easy visual monitoring of the device's status, and comes with a Y interconnecting cable and windscreen foam to ensure optimal performance in any situation.

Conference system
Microphone
  • Unidirectional electret condenser with LED ring
Inputs
  • XLR female 3 PIN
Outputs
  • DIN male 8 PIN
Frequency response
  • 50-20,000 Hz
Sensitivity
  • -42 dB ±3 dB (V/Pa) @ 1 kHz
Impedance
600 Ω
SPL max.
128 dB
Equivalent noise
33 dB
Dynamic range
95 dB
Distortion
  • < 1 %
S/N ratio
  • > 61 dB
Indicators
  • LED operation ring
  • LED power indicator
Temperature range
-20 °C - 50 °C
Power supply
  • 18 V DC, supplied by the control unit
Cable
  • 1.2 m DIN male 8 PIN
Dimensions
  • Base: 93 x 46 x 122 mm depth
  • Gooseneck microphone: 45 cm height
Weight
  • 0.68 kg
Accessories
  • 1 Y interconnecting cable, 2 + 0'2 m DIN 8 male to 2 DIN 8 female
  • Foam windshield
Compatibility
  • SCF-250: Conference system
